General data: | |
---|---|
Type: Maritime Patrol Aircraft (MPA) | Crew: 11 |
Min Speed: 250 kt | Max Speed: 470 kt |
Wingspan: 53.1 m | Height: 12.2 m |
Length: 49.5 m | Max Payload: 15000 kg |
Empty Weight: 91800 kg | Max Weight: 155000 kg |
Operator: Navy | Commissioned: 1992 |
Propulsion: 4x NK-12MA |
Sensors / EW: |
---|
Wet Eye [Berkut-95] - Radar Radar, Surface Search, Medium-Range Max Range: 277.8 km |
ELINT [Kvadrat-2] - (Il-20M, Tu-95RT, Fine Analysis) ESM ELINT Max Range: 926 km |
Box Tail [PRS-4 Krypton] - (Il-20M, Tu-95RT, Fine Analysis) Radar TWR, Tail Warning Radar & Tail Gun Director Max Range: 18.5 km |
DECM [Sayany-M] - (Tu-142) ECM DECM, Defensive ECM Max Range: 0 km |
SPO-10 Sirena-3M - (Tu-142) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Generic Tail Gun Director [TV Camera] - (1st Gen) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km |
MAD [APM-60] - (Berkut/Kalmar System, Ka-25, Mi-14, 1st Gen) MAD MAD Max Range: 1.9 km |
Weapons / Loadouts: |
---|
AT-2M -
(1975?) Torpedo Subsurface Max: 1.9 km. |
APR-1 Kondor -
(1972, Aircraft-Only) Torpedo Subsurface Max: 0.9 km. |
RGB-1 [NATO BM-1, Search, Passive Omni] -
(Berkut System, 1969, 35/70m, 3hr) Sonobuoy |
RGB-2 [NATO BM-2, Track, Passive Bearing-Only] -
(Berkut System, 1969, 20m, 45min) Sonobuoy |
