General data:
Type: Fighter Crew: 1
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 14 m Height: 4.8 m
Length: 16.7 m Max Payload: 2000 kg
Empty Weight: 10230 kg Max Weight: 17800 kg
Operator: Air Force Commissioned: 2000
Propulsion: 1x R-35-300 Decommissioned: 2003
Sensors / EW:
High Lark 2 [Sapfir-23ML] - Radar
Radar, FCR, Air-to-Air, Short-Range
Max Range: 74.1 km
IRST [TP-23-1] - (Export MiG-23MF/ML) Infrared
IRST, Non-Imaging Infrared Search and Track
Max Range: 37 km
SPO-10 Sirena-3M - (Export MiG-23MF/ML) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
AA-7 Apex C [R-24R, SARH] - (1981, Izdeliye 140) Guided Weapon
Air Max: 50 km.
AA-8 Aphid [R-60] - (1974) Guided Weapon
Air Max: 9.3 km.
800 liter Drop Tank - Drop Tank
OFAB-100-120 Frag - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
FAB-250M-54 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
FAB-500M-54 GPB - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
RBK-250-PTAB CB [30 x PTAB-2.5 Anti-Tank Bomblets] - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
RBK-500-PTAB [268 x PTAB-1M Anti-Tank Bomblets] - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
S-5K 57mm Rocket - (OOS ~2014, Superseded by S-8) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
S-24B 240mm Rocket - (V-24A Fuze) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
OFAB-250-270 Frag - Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
AA-7 Apex D [R-24T, IR] - (1981, Izdeliye 160) Guided Weapon
Air Max: 50 km.
TMV-002 Remora DECM Pod - (1984, Associated with BF RWR) Sensor Pod
