General data: | |
---|---|
Type: Fighter | Crew: 1 |
Min Speed: 350 kt | Max Speed: 920 kt |
Wingspan: 14 m | Height: 4.8 m |
Length: 16.7 m | Max Payload: 2000 kg |
Empty Weight: 10230 kg | Max Weight: 17800 kg |
Operator: Air Force | Commissioned: 1991 |
Propulsion: 1x R-35-300 |
Sensors / EW: |
---|
SPO-3 Sirena-3 - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
High Lark 2 [Sapfir-23ML] - Radar Radar, FCR, Air-to-Air, Short-Range Max Range: 74.1 km |
IRST [TP-23-1] - (Export MiG-23MF/ML) Infrared IRST, Non-Imaging Infrared Search and Track Max Range: 37 km |
Weapons / Loadouts: |
---|
AA-7 Apex C [R-24R, SARH] -
(1981, Izdeliye 140) Guided Weapon Air Max: 50 km. |
AA-8 Aphid [R-60] -
(1974) Guided Weapon Air Max: 9.3 km. |
800 liter Drop Tank -
Drop Tank |
OFAB-100-120 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
FAB-250M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
FAB-500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
RBK-250-PTAB CB [30 x PTAB-2.5 Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
RBK-500-PTAB [268 x PTAB-1M Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
S-5K 57mm Rocket -
(OOS ~2014, Superseded by S-8) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
S-24B 240mm Rocket -
(V-24A Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
OFAB-250-270 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
