| General data: | |
|---|---|
| Type: Fighter | Crew: 1 |
| Min Speed: 350 kt | Max Speed: 1000 kt |
| Wingspan: 14.3 m | Height: 6 m |
| Length: 21.4 m | Max Payload: 4500 kg |
| Empty Weight: 16500 kg | Max Weight: 38000 kg |
| Operator: Air Force | Commissioned: 2020 |
| Propulsion: 2x AL-41F1A |
| Sensors / EW: |
|---|
| N036-1-01 Byelka AESA - (Su-57) Radar Radar, FCR, Air-to-Air & Air-to-Surface, Long-Range Max Range: 398.2 km |
| N036B-1-01 Byelka AESA - (Su-57, Cheek Mounted) Radar SLAR, Side-Looking Airborne Radar Max Range: 148.2 km |
| N036L-1-01 Byelka AESA - (Su-57, Wing Mounted, Range/Azimuth Only) Radar Radar, Air Search, 2D Medium-Range Max Range: 222.2 km |
| 101KS-V - (Atoll) Infrared IRST, Imaging Infrared Search and Track Max Range: 185.2 km |
| 101KS-V [Laser Rangefinder] - (Atoll) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
| 101KS-P - (Atoll, Terrain Avoidance & Landing Aid) Infrared Infrared, Surveillance Camera Max Range: 46.3 km |
| 101KS-U MAWS - (Atoll, 101KS-U/01, 101KS-U/02) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| 101KS-O DIRCM - (Atoll) ECM IRCM Max Range: 0 km |
| L402 Himalayas [RWR] - (Atoll) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| L402 Himalayas [DECM] - (PAK-FA) ECM DECM, Defensive ECM Max Range: 0 km |
| L402 Himalayas [OECM] - (PAK-FA) ECM OECM, Offensive ECM Max Range: 0 km |
| Weapons / Loadouts: |
|---|
| AA-12 Adder C [R-77M] -
(PAK-FA, Izdeliye 180) Guided Weapon Air Max: 188.9 km. |
| AA-11 Archer [R-74M2] -
(PAK-FA, Izdeliye 760) Guided Weapon Air Max: 27.8 km. |
| 2000 liter Drop Tank -
Drop Tank |
| AA-13 Arrow [R-37M, RVV-BD] -
(2019, Izdeliye 610M, Axehead) Guided Weapon Air Max: 300 km. |
| AS-11 Kilter [Kh-58UShK, ARM, Semi-Ballistic] -
(PAK-FA) Guided Weapon Surface Max: 240.8 km. Land Max: 240.8 km. |
| PBK-500U Unitary [INS + GLONASS] -
(2016?) Guided Weapon Land Max: 27.8 km. |
| PBK-500U SPBE-K [INS + GLONASS] -
(2016?) Guided Weapon Land Max: 30 km. |
| AS-22 [Kh-38MKE] -
(GLONASS) Guided Weapon Land Max: 37 km. |
| AS-17 Krypton C [Kh-31P, ARM] -
Guided Weapon Surface Max: 111.1 km. Land Max: 111.1 km. |
| AS-18 Kazoo A [Kh-59M] -
(1993) Guided Weapon Surface Max: 111.1 km. Land Max: 111.1 km. |
