General data:
Type: Multirole (Fighter/Attack) Crew: 1
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 8.0 m Height: 4.1 m
Length: 14.4 m Max Payload: 0 kg
Empty Weight: 4392 kg Max Weight: 11214 kg
Operator: Air Force Commissioned: 2007
Propulsion: 2x J85-GE-21
Sensors / EW:
EL/M-2032B - Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range
Max Range: 111.1 km
EWPS-100 [DECM] - (A-401, Chile) ECM
DECM, Defensive ECM
Max Range: 0 km
EWPS-100 [RWR] - (DM, A-104, Chile) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Tie Rod - (DM, A-104, Chile) Visual
Visual, Surveillance TV Camera
Max Range: 55.6 km
Grifo F-BR - (F-5E/F) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 74.1 km
Weapons / Loadouts:
MAA-1 Piranha - (2004) Guided Weapon
Air Max: 14.8 km.
275 USG Drop Tank - Drop Tank
Mk82 500lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk83 1000lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
HYDRA 70mm Rocket - (Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
Litening III Pod [FLIR + LRMTS, 40k ft] - Sensor Pod
Lizard 2 LGB [Mk82] - (1998, Israel) Guided Weapon
Surface Max: 7.4 km. Land Max: 7.4 km.
Derby - (2002) Guided Weapon
Air Max: 74.1 km.
Python 4 - (1994) Guided Weapon
Air Max: 18.5 km.
