| General data: | |
|---|---|
| Type: Recon | Crew: 1 |
| Min Speed: 150 kt | Max Speed: 430 kt |
| Wingspan: 31.4 m | Height: 4.9 m |
| Length: 19.2 m | Max Payload: 2270 kg |
| Empty Weight: 7264 kg | Max Weight: 18598 kg |
| Operator: Air Force | Commissioned: 2005 |
| Propulsion: 1x F118-GE-101 |
| Sensors / EW: |
|---|
| SYERS-2 - (U-2) Infrared Infrared, Surveillance Camera Max Range: 185.2 km |
| Optical Bar Camera [OTHC] - (U-2) Visual Visual, Reconnaissance Very Long-Range Frame Camera Max Range: 148.2 km |
| AN/ALQ-221 [RWR] - (U-2) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/ALQ-221 [DECM] - (U-2) ECM DECM, Defensive ECM Max Range: 0 km |
| ASARS-2A - (2002, U-2 SAR) Radar Radar, Surface Search, Medium-Range Max Range: 185.2 km |
| ASIP - (U-2S, RQ-4) ESM ELINT Max Range: 926 km |
