| General data: | |
|---|---|
| Type: Attack | Crew: 2 |
| Min Speed: 55 kt | Max Speed: 160 kt |
| Wingspan: 3.3 m | Height: 4.1 m |
| Length: 13.6 m | Max Payload: 0 kg |
| Empty Weight: 2990 kg | Max Weight: 4540 kg |
| Operator: Marine Corps | Commissioned: 1983 |
| Propulsion: 1x T400-CP-400 | Decommissioned: 1993 |
| Sensors / EW: |
|---|
| AN/APR-39(V)2 - (USN/USMC) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons / Loadouts: |
|---|
| HYDRA 70mm Rocket -
(Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| BGM-71C Improved TOW -
(1981) Guided Weapon Surface Max: 3.7 km. Land Max: 3.7 km. |
| BGM-71D TOW 2 -
(1983) Guided Weapon Surface Max: 3.7 km. Land Max: 3.7 km. |
| BGM-71B TOW -
(1976, Helicopter) Guided Weapon Surface Max: 3.7 km. Land Max: 3.7 km. |
| ZUNI 127mm HVAR Rocket -
Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| AIM-9L Sidewinder -
(1980) Guided Weapon Air Max: 18.5 km. |
| CBU-55/B Fuel Air Explosive [3 x BLU-73/B] -
(SUU-49) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
