General data:
Type: Anti-Satellite Interceptor (ASAT) Crew: 1
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 13.1 m Height: 4.65 m
Length: 19.3 m Max Payload: 7260 kg
Empty Weight: 12710 kg Max Weight: 25400 kg
Operator: Air Force Commissioned: 1985
Propulsion: 2x F100-PW-100 Decommissioned: 1985
Sensors / EW:
AN/ALQ-128 EEWS - ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/ALQ-135 TEWS Upgrade - ECM
DECM, Defensive ECM
Max Range: 0 km
AN/APG-63 - Radar
Radar, FCR, Air-to-Air, Medium-Range
Max Range: 175.9 km
AN/ALR-56A TEWS - ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
ASM-135A ALMV - (1985-1985, ASAT) Guided Weapon
Air Max: 463 km.
600 USG Drop Tank - Drop Tank
Open Description
