General data: | |
---|---|
Type: Maritime Patrol Aircraft (MPA) | Crew: 12 |
Min Speed: 170 kt | Max Speed: 350 kt |
Wingspan: 37.4 m | Height: 10.9 m |
Length: 31.6 m | Max Payload: 3500 kg |
Empty Weight: 25700 kg | Max Weight: 46200 kg |
Operator: Navy | Commissioned: 1979 |
Propulsion: 2x Tyne RTy.20 Mk.21 |
Sensors / EW: |
---|
DHAX 1 - (Atlantique 1) MAD MAD Max Range: 1.9 km |
ARAR-10B [DR 2000A] - (Atlantique 1) ESM ELINT Max Range: 926 km |
Generic FLIR - (DEPRECATED - 1st Gen, Surveillance & Periscope Search) Infrared Infrared, Surveillance Camera Max Range: 27.8 km |
DRAA-2B - (DEPRECATED - 1st Gen, Surveillance & Periscope Search) Radar Radar, Surface Search, Long-Range Max Range: 370.4 km |
Weapons / Loadouts: |
---|
Mk46 LWT Mod 2 -
(1972) Torpedo Subsurface Max: 5.6 km. |
BIT-3 LOFAR -
(Italy, 1980, A-Size, 31 Chn, 1/3hr, 20/100m, Impr SSQ-41 Replacement) Sonobuoy |
AN/SSQ-47 Julie Active Range-Only -
(1967-1995, SSQ-522, SSQ-947, HQS-31, A-Size, 12 Chn, 18/243m, 30min, Ranger Buoy, Exported) Sonobuoy |
