General data: | |
---|---|
Type: Attack | Crew: 1 |
Min Speed: 350 kt | Max Speed: 920 kt |
Wingspan: 8.9 m | Height: 0 m |
Length: 17 m | Max Payload: 0 kg |
Empty Weight: 8620 kg | Max Weight: 19500 kg |
Operator: Air Force | Commissioned: 1970 |
Propulsion: 1x AL-7F-1 | Decommissioned: 1984 |
Sensors / EW: |
---|
High Fix [SRD-5ND Kvant] - Radar Radar, Range-Only (RO) Max Range: 7.4 km |
SPO-3 Sirena-3 - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Weapons / Loadouts: |
---|
OFAB-100-120 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
FAB-250M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
RBK-250-PTAB CB [30 x PTAB-2.5 Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
S-5K 57mm Rocket -
(OOS ~2014, Superseded by S-8) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
620 liter Drop Tank -
Drop Tank |
FAB-500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
RBK-500-PTAB [268 x PTAB-1M Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
OFAB-250-270 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
