General data:
Type: Maritime Patrol Aircraft (MPA) Crew: 11
Min Speed: 250 kt Max Speed: 470 kt
Wingspan: 53.1 m Height: 12.2 m
Length: 49.5 m Max Payload: 15000 kg
Empty Weight: 91800 kg Max Weight: 155000 kg
Operator: Naval Aviation [AV-MF] Commissioned: 1981
Propulsion: 4x NK-12MA Decommissioned: 1991
Sensors / EW:
Wet Eye [Korshun] - Radar
Radar, Surface Search, Medium-Range
Max Range: 277.8 km
MAD [APM-73B] - (Korshun System, Ka-27) MAD
MAD
Max Range: 1.9 km
ELINT [Kvadrat-2] - (Il-20M, Tu-95RT, Fine Analysis) ESM
ELINT
Max Range: 926 km
Box Tail [PRS-4 Krypton] - (Il-20M, Tu-95RT, Fine Analysis) Radar
TWR, Tail Warning Radar & Tail Gun Director
Max Range: 18.5 km
DECM [Sayany-M] - (Tu-142) ECM
DECM, Defensive ECM
Max Range: 0 km
SPO-10 Sirena-3M - (Tu-142) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Generic Tail Gun Director [TV Camera] - (2nd Gen) Visual
Visual, Weapon Director TV Camera
Max Range: 185.2 km
Weapons / Loadouts:
AT-2M - (1975?) Torpedo
Subsurface Max: 1.9 km.
APR-1 Kondor - (1972, Aircraft-Only) Torpedo
Subsurface Max: 0.9 km.
RGB-75 [Basic Search, Passive Omni] - (Korshun System, 150m, 5hr, Primary Type, LOFAR) Sonobuoy
RGB-15 [Refined Search, Passive Omni] - (Korshun System, 20/150/400m, 2hr, Straight/Curved Barrier) Sonobuoy
RGB-25 [Track, Passive Directional] - (Korshun System, 20/150m, 45min) Sonobuoy
RGB-55A [Track, Active/Passive] - (Korshun System, 20/200m, 2hr) Sonobuoy
