General data: | |
---|---|
Type: Attack | Crew: 1 |
Min Speed: 350 kt | Max Speed: 920 kt |
Wingspan: 8.4 m | Height: 4.5 m |
Length: 15.3 m | Max Payload: 0 kg |
Empty Weight: 7400 kg | Max Weight: 16200 kg |
Operator: Air Force | Commissioned: 1987 |
Propulsion: 1x Atar 9K-50 |
Sensors / EW: |
---|
Cyrano IV-M - Radar Radar, FCR, Air-to-Air & Air-to-Surface, Medium-Range Max Range: 111.1 km |
Type BF - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Weapons / Loadouts: |
---|
AM.39 Exocet Blk I -
(1980) Guided Weapon Surface Max: 66.7 km. |
1200 liter Drop Tank -
Drop Tank |
TMV-002 Remora DECM Pod -
(1984, Associated with BF RWR) Sensor Pod |
R.550 Magic 1 -
(1976) Guided Weapon Air Max: 9.3 km. |
Super R.530F -
(1981, SARH) Guided Weapon Air Max: 40.7 km. |
ARMAT [ARM] -
(1984-1999) Guided Weapon Surface Max: 101.9 km. Land Max: 101.9 km. |
T.25 250kg GPB -
(France) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
SNEB 68mm Rocket -
(TDA 68mm, TBA 68mm) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
2200 liter Drop Tank -
Drop Tank |
Generic Camera Pod [Visual] -
Sensor Pod |
