General data:
Type: Attack Crew: 5
Min Speed: 180 kt Max Speed: 325 kt
Wingspan: 40.4 m Height: 11.6 m
Length: 29.8 m Max Payload: 19090 kg
Empty Weight: 34400 kg Max Weight: 70300 kg
Operator: Air Force Commissioned: 2000
Propulsion: 4x T56-A-15 Decommissioned: 2015
Sensors / EW:
AN/AAQ-26 - Infrared
Infrared, Target Search, Tracking and Identification Camera
Max Range: 50 km
AN/ALR-69 - ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Generic Gun Director [LLTV] - (2nd Gen, Anti-Air & Surface) Visual
LLTV, Weapon Director
Max Range: 148.2 km
AN/APQ-150 - (AC-130E) Radar
Radar, Ground Mapping
Max Range: 74.1 km
AN/ALQ-172(V)1 - (MC-130H, AC-130U) ECM
DECM, Defensive ECM
Max Range: 0 km
AN/APQ-122(V)5 - (MC-130H, AC-130U) Radar
Radar, Ground Mapping
Max Range: 277.8 km
Generic Laser Rangefinder for Gun Director - (Anti-Air & Surface) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
