| General data: | |
|---|---|
| Type: Recon | Crew: 2 |
| Min Speed: 350 kt | Max Speed: 920 kt |
| Wingspan: 16.1 m | Height: 5.9 m |
| Length: 22.3 m | Max Payload: 0 kg |
| Empty Weight: 17024 kg | Max Weight: 36132 kg |
| Operator: Navy | Commissioned: 1964 |
| Propulsion: 2x J79-GE-8 | Decommissioned: 1979 |
| Sensors / EW: |
|---|
| AN/ALQ-51 - (Assoc w AN/ALQ-41, Deception Jammer) ECM DECM, Defensive ECM Max Range: 0 km |
| AN/ALQ-100 - (Assoc w AN/ALQ-41, Deception Jammer) ECM DECM, Defensive ECM Max Range: 0 km |
| AN/AAS-21 - (RA-5C) Infrared IRLS, Non-Imaging Infrared Line Scanner Max Range: 9.3 km |
| AN/APD-7 - (RA-5C) Radar SLAR, Side-Looking Airborne Radar Max Range: 74.1 km |
| KA-51A - (RA-5C) Visual Visual, Reconnaissance Frame Camera Max Range: 9.3 km |
| AN/ALQ-61 - (RA-5C) ESM ELINT Max Range: 926 km |
| AN/ALR-50 Charger Blue - (Navy) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/ALR-45 Compass Tie - (Navy) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/ALQ-41 - (Assoc w AN/ALQ-51, Track Breaker) ECM DECM, Defensive ECM Max Range: 0 km |
| Weapons / Loadouts: |
|---|
| 400 USG Drop Tank -
Drop Tank |
