| General data: | |
|---|---|
| Type: Electronic Warfare | Crew: 10 |
| Min Speed: 300 kt | Max Speed: 550 kt |
| Wingspan: 33 m | Height: 10.4 m |
| Length: 34.8 m | Max Payload: 0 kg |
| Empty Weight: 36600 kg | Max Weight: 79000 kg |
| Operator: Long Range Aviation [DA] | Commissioned: 1983 |
| Propulsion: 2x RD-3M | Decommissioned: 1991 |
| Sensors / EW: |
|---|
| Short Horn [RPB-4 Rubin-1] - (Tu-16R) Radar Radar, Surface Search, Long-Range Max Range: 324.1 km |
| SPS-151/152/153 Lyutik - (Tu-16) ECM DECM, Defensive ECM Max Range: 0 km |
| SPS-61/62/63 Azaliya - (Tu-16, Assoc w SPS-6 Los) ECM OECM, Offensive ECM Max Range: 0 km |
| SPS-6 Los - (Tu-16) ECM OECM, Offensive ECM Max Range: 0 km |
| SRS-4 Romb - (Tu-16) ESM ELINT Max Range: 926 km |
