General data:
Type: Multirole (Fighter/Attack) Crew: 1
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 9.5 m Height: 4.8 m
Length: 14.5 m Max Payload: 6894 kg
Empty Weight: 7395 kg Max Weight: 19200 kg
Operator: Air Force Commissioned: 1991
Propulsion: 1x F100-PW-200
Sensors / EW:
AN/APG-66 - Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 74.1 km
AN/ALR-69 - ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons / Loadouts:
300 USG Drop Tank - Drop Tank
370 USG Drop Tank - Drop Tank
AN/ALQ-131 DECM Pod - (1983?) Sensor Pod
AIM-9P-4 Sidewinder - (1980) Guided Weapon
Air Max: 18.5 km.
AIM-9L Sidewinder - (1980) Guided Weapon
Air Max: 18.5 km.
Mk82 500lb LDGP - (1954) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk84 2000lb LDGP - (1955) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk20 Rockeye II CB [247 x Mk118 Dual Purpose Bomblets] - (1969, Mk7 Dispenser) Bomb
Surface Max: 1.9 km. Land Max: 1.9 km.
HYDRA 70mm Rocket - (Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
Atlis Pod [EO + LRMTS, 12k ft] - (1980) Sensor Pod
AS.30L - (1989) Guided Weapon
Surface Max: 11.1 km. Land Max: 11.1 km.
R.550 Magic 2 Mk1 - (1986) Guided Weapon
Air Max: 14.8 km.
