General data: | |
---|---|
Type: Attack | Crew: 2 |
Min Speed: 350 kt | Max Speed: 920 kt |
Wingspan: 13.9 m | Height: 5.95 m |
Length: 16.7 m | Max Payload: 9000 kg |
Empty Weight: 14090 kg | Max Weight: 28000 kg |
Operator: Air Force | Commissioned: 1991 |
Propulsion: 2x RB.199-34R Mk.103 |
Sensors / EW: |
---|
Tornado Nose Radar (TNR) [TFR & GMR] - Radar Radar, FCR, Air-to-Surface, Short-Range Max Range: 74.1 km |
ERWE - (Tornado, Germany) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Weapons / Loadouts: |
---|
AGM-88B HARM -
(1990) Guided Weapon Surface Max: 129.6 km. Land Max: 129.6 km. |
BOZ-101 Chaff/Flare Pod -
Sensor Pod |
AIM-9L Sidewinder -
(1980) Guided Weapon Air Max: 18.5 km. |
Cerberus III DECM Pod -
(1986) Sensor Pod |
1500 liter Drop Tank -
Drop Tank |
AGM-65D Maverick IR -
(1984) Guided Weapon Surface Max: 14.8 km. Land Max: 14.8 km. |
BL.755 No.1 CB [147 x GP Anti-Armor Bomblets] -
(1973) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
Mk82 500lb AIR [Ballute] -
(1986) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
MW-1 Anti-Armour Dispenser [2268 x Anti-Tank + 336 Anti-Personnel] -
(1985) Dispenser Land Max: 1.9 km. |
MW-1 Anti-Runway Dispenser [100 x Runway Penetrators + 336 x Area Denial Mines] -
(1988) Dispenser Land Max: 1.9 km. |
Generic Buddy Store -
Buddy Store |
B61 Tactical/Strategic Bomb [340kT Nuclear] -
(1968) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
