General data:
Type: SSN - Nuclear Powered Attack Submarine Max Depth: -400 m
Commissioned: 1973 Length: 92.5 m
Beam: 11.7 m Draft: 7.4 m
Crew: 110 Displacement: 4100 t
Propulsion: 2x VM-4T Nuclear Reactors, 22.7MW Max Speed: 30 kt
Decommissioned: 1991
Sensors / EW:
Shark Sail [MGK-300 Rubin] - Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept
Max Range: 27.8 km
Park Lamp - ESM
HF/DF
Max Range: 926 km
Mine Avoidance [MG-509 Radian-1] - (Papa, Victor I/II) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mine & Obstacle Avoidance
Max Range: 0.9 km
Brick Pulp [MRP-21 Zaliv-P] - (Victor, Charlie) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Snoop Tray 2 [MRK-50 Kaskad] - (Victor, Charlie) Radar
Radar, Surface Search, Short-Range
Max Range: 37 km
Shark Teeth [MGK-300 Rubin] - (Victor, Charlie) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 14.8 km
Weapons:
Generic Acoustic Decoy - (1970s, Noisemaker / Bubble Screen) Decoy (Expendable)
Subsurface Max: 1.9 km.
SA-N-8 Gremlin [9M36] - (9K34 Strela-3) Guided Weapon
Air Max: 5.6 km.
53-65K WH - (1972, Submarine, Widely Used) Torpedo
Surface Max: 7.4 km.
53-65N Gyro [NATO 53-68N, 20kT Nuclear] - (1971, Submarine) Torpedo
Surface Max: 7.4 km.
SET-65M Enot-2 [NATO ET-80A[76]] - (1973, Submarine) Torpedo
Subsurface Max: 7.4 km.
