General data:
Type: SSN - Nuclear Powered Attack Submarine Max Depth: -220 m
Commissioned: 1978 Length: 77.0 m
Beam: 9.6 m Draft: 9.0 m
Crew: 93 Displacement: 3075 t
Propulsion: 1x S5W Nuclear Reactor Max Speed: 28 kt
Sensors / EW:
AN/WLR-11 - (RWR for AN/WLR-1G, Improved AN/WLR-3 & AN/ALR-52) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/WLR-1G - (RWR for AN/WLR-1G, Improved AN/WLR-3 & AN/ALR-52) ESM
ELINT
Max Range: 926 km
AN/BQR-25 STASS - (RWR for AN/WLR-1G, Improved AN/WLR-3 & AN/ALR-52) TASS, Passive-Only Towed Array Sonar System
TASS, Passive-Only Towed Array Sonar System
Max Range: 74.1 km
AN/BQR-21 - (1976, Lafayette, AN/BQR-2 Upgrade) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Search & Track
Max Range: 74.1 km
AN/BPS-12 - (1976, Lafayette, AN/BQR-2 Upgrade) Radar
Radar, Surface Search, Short-Range
Max Range: 74.1 km
AN/BQS-4 Mod 1 - (Skipjack) Hull Sonar, Active-Only
Hull Sonar, Active-Only Search
Max Range: 7.4 km
AN/WLR-9 - (AN/BLR-14, Sonar Warning Receiver) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept & Torpedo Warning
Max Range: 27.8 km
Weapons:
Mk48 Mod 3 - (1978) Torpedo
Surface Max: 11.1 km. Subsurface Max: 11.1 km.
