General data:
Type: SS - Attack/Fleet Submarine Max Depth: -300 m
Commissioned: 1979 Length: 67.6 m
Beam: 6.8 m Draft: 5.4 m
Crew: 54 Displacement: 1490 t
Propulsion: Electric Motors Max Speed: 20 kt
Sensors / EW:
TRS 3100 Calypso III [DRUA 33C] - Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 37 km
DUUX 2B - (Side-Looking) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Ranging Flank Array Search & Track
Max Range: 27.8 km
DUUA 2B - (1979, Passive, Assoc w DUUA 2B) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Search & Track
Max Range: 7.4 km
DUUA 1A - (Basic Searchlight) Hull Sonar, Active-Only
Hull Sonar, Active-Only Search & Track
Max Range: 5.6 km
DR 2000U - (ARUR-10, ARUD 10) ESM
ELINT
Max Range: 926 km
DSUV 2H - (Assoc w DUUA 2D) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Search & Track
Max Range: 7.4 km
DUUG 6 [M5] - (Assoc w DUUA 2D) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept
Max Range: 27.8 km
DUUG 5 - (TSM 2243, Assoc w DUUG 6, Used w DSUV 22/TSM 2233) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept, Surveillance
Max Range: 27.8 km
Weapons:
E18 - (Export, 533mm) Torpedo
Surface Max: 7.4 km. Subsurface Max: 5.6 km.
Generic Acoustic Decoy - (1970s, Noisemaker / Bubble Screen) Decoy (Expendable)
Subsurface Max: 1.9 km.
