General data:
Type: SSN - Nuclear Powered Attack Submarine Max Depth: -450 m
Commissioned: 1992 Length: 111.0 m
Beam: 14.2 m Draft: 9.4 m
Crew: 91 Displacement: 7600 t
Propulsion: 1x OK-650 Nuclear Reactor, 190MW Max Speed: 35 kt
Sensors / EW:
Shark Rib [MGK-540 Skat-3] - (Flank Array) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Ranging Flank Array Search & Track
Max Range: 74.1 km
Rim Hat [Kremlin-2] - (Flank Array) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Shark Tail [MG-541 Skat-3] - (Flank Array) TASS, Passive-Only Towed Array Sonar System
TASS, Passive-Only Towed Array Sonar System
Max Range: 129.6 km
Shark Gill [MGK-540 Skat-3] - (Flank Array) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 74.1 km
Park Lamp - (Flank Array) ESM
HF/DF
Max Range: 926 km
Snoop Pair [MRKP-58 Radian] - (Akula) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Mouse Roar [MG-519 Arfa-M] - (MGK-500 Suite) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mine & Obstacle Avoidance
Max Range: 0.9 km
Generic Acoustic Intercept - (MGK-500 Suite) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept
Max Range: 27.8 km
Weapons:
Generic Acoustic Decoy - (1980s, Noisemaker / Bubble Screen) Decoy (Expendable)
Subsurface Max: 1.9 km.
SA-N-8 Gremlin [9M36] - (9K34 Strela-3) Guided Weapon
Air Max: 5.6 km.
USET-80K - (1990) Torpedo
Surface Max: 9.3 km. Subsurface Max: 9.3 km.
SS-N-15 Starfish [RPK-6 Vodopad, UMGT-1 Torpedo] - (1982, 83R) Guided Weapon
Subsurface Max: 40.7 km.
MG-74 - (Torpedo Decoy) Decoy (Expendable)
Subsurface Max: 1.9 km.
