General data:
Type: SSK - Hunter-Killer Submarine Max Depth: -200 m
Commissioned: 1995 Length: 48.6 m
Beam: 4.6 m Draft: 4.5 m
Crew: 22 Displacement: 450 t
Propulsion: Electric Motors Max Speed: 17 kt
Decommissioned: 2010
Sensors / EW:
PRS 3-15 - (Passive Ranging for CSU 83/93) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Ranging Flank Array Search & Track
Max Range: 14.8 km
THD 1030 Calypso II - (Passive Ranging for CSU 83/93) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 37 km
DBQS-21 [CSU 83] - (Passive Ranging for CSU 83/93) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 29.6 km
AR-700S5 - (Submarine) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
DR 2000U - (ARUR-10, ARUD 10) ESM
ELINT
Max Range: 926 km
DBQS-21 Intercept [IPS CSU 83] - (Assoc w CSU 83) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept
Max Range: 27.8 km
EDO 900 - (Assoc w CSU 83) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mine & Obstacle Avoidance
Max Range: 0.4 km
Weapons:
Generic Acoustic Decoy - (1990s, Noisemaker / Bubble Screen) Decoy (Expendable)
Subsurface Max: 1.9 km.
DM2A3 Seehecht - (1991, Seahake) Torpedo
Surface Max: 9.3 km. Subsurface Max: 9.3 km.
