General data:
Type: FFG - Guided Missile Frigate Max Speed: 32 kt
Crew: 163 Length: 117.5 m
Beam: 14.8 m Draft: 6.0 m
Displacement Full: 3600 t Displacement: 3300 t
Operator: Navy Commissioned: 2013
Propulsion: 2x MTU 12V 1163 TB83 Diesels, 1x General Electric LM-2500-30 Gas Turbine, CODOG
Sensors / EW:
Telegon 10 - (PGS 1720) ESM
HF/DF
Max Range: 926 km
AN/SPS-49(V)8 - (PGS 1720) Radar
Radar, Air Search, 2D Long-Range
Max Range: 463 km
Atlas 9600-M ARPA - (PGS 1720) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Sea Giraffe 150 HC - (1990, CA/SPS-505, PS 76) Radar
Radar, Target Indicator, 3D Surface-to-Air
Max Range: 100 km
Cenatur - (Spectre XL Upgr) ESM
ELINT
Max Range: 926 km
CEA-MOUNT - (Four-Faced Illuminator) Radar
Radar Illuminator, Long-Range
Max Range: 111.1 km
EOS 500 [CCD] - (Group, 9GR400) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, 9GR400) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, 9GR400) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
CEROS 200 Tracker [9LV Mk4 ESSM] - (Group, 9GR400) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 74.1 km
VAMPIR-NG [CCD] - (Group) Visual
LLTV, Target Search, Slaved Tracking and Identification
Max Range: 185.2 km
VAMPIR-NG [IR] - (Group) Infrared
Infrared, Target Search, Slaved Tracking and Identification Camera
Max Range: 185.2 km
VAMPIR-NG [Laser Rangefinder] - (Group) Laser Rangefinder
Laser Rangefinder
Max Range: 7.4 km
UMS 4131S [Spherion Mk3] - (Ex-TMS 4131S, MFS 2000 Processor) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 74.1 km
CEA-FAR - (Six-Faced 3D) Radar
Radar, FCR, Surface-to-Air, Medium-Range
Max Range: 203.7 km
Weapons:
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
127mm/54 HE-CVT [HiFrag] - (USN) Gun
Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km.
127mm/54 HE-PD [HiCap] - (USN) Gun
Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km.
RGM-84L Harpoon II - (2003) Guided Weapon
Surface Max: 138.9 km. Land Max: 138.9 km.
MU-90 Impact - (2003, Ex-Murene, Ex-A.290) Torpedo
Subsurface Max: 7.4 km.
LRCR Chaff - (179mm, Israel) Decoy (Expendable)
Surface Max: 1.9 km.
PIRATE Flare - Decoy (Expendable)
Surface Max: 1.9 km.
Mk234 Nulka - (2002) Decoy (Expendable)
Surface Max: 1.9 km.
RIM-162B ESSM - (2004, non-AEGIS, Mk41) Guided Weapon
Air Max: 55.6 km. Surface Max: 46.3 km.
AN/SLQ-25A Nixie - Decoy (Towed)
Surface Max: 1.9 km.
