General data:
Type: FFG - Guided Missile Frigate Max Speed: 26 kt
Crew: 118 Length: 88.9 m
Beam: 10.4 m Draft: 4.0 m
Displacement Full: 1640 t Displacement: 1428 t
Operator: Navy Commissioned: 1985
Propulsion: 4x MTU-Bazan 16V 956 TB91 Diesels
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
WM.25 - (Low-Level AD, Missile FCS) Radar
Radar Illuminator, Long-Range
Max Range: 118.5 km
DA.05 [RAWS-3] - (Low-Level AD, Missile FCS) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 237.1 km
ZW.06 - (1972, PIN 515) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
DE 1160B - (Export Version) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 9.3 km
Generic Navigation Radar - (Export Version) Radar
Radar, Navigation
Max Range: 37 km
Newton Beta [ELT 318/521, ECM] - (Export Version) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Galileo OG R7/2 - (Galileo OG 20) Visual
Visual, Weapon Director TV Camera
Max Range: 129.6 km
Newton Beta [ELT 211, ESM] - (Galileo OG 20) ESM
ELINT
Max Range: 926 km
Weapons:
Bofors 375mm ASW Rocket Salvo [2 rnds] - Rocket
Subsurface Max: 3.7 km.
76mm/62 Compact HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
RIM-7M Sea Sparrow - (1985) Guided Weapon
Air Max: 25.9 km. Surface Max: 25.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk182 SRBOC Chaff [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk46 LWT Mod 2 - (1972) Torpedo
Subsurface Max: 5.6 km.
RGM-84D Harpoon IC - (1986) Guided Weapon
Surface Max: 138.9 km.
40mm/70 Single Breda Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
