General data:
Type: FFG - Guided Missile Frigate Max Speed: 30 kt
Crew: 199 Length: 130.0 m
Beam: 14.4 m Draft: 6.5 m
Displacement Full: 3800 t Displacement: 2950 t
Operator: Navy Commissioned: 2006
Propulsion: 2x MTU 20V 956 TB92 Diesels, 2x General Electric-Fiat LM-2500 Gas Turbines, CODOG Decommissioned: 2019
Sensors / EW:
DSQS-21B [CSU 83] - (FF/DD, Assoc w ASO 85) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 29.6 km
Telegon 6 - (CXA(1)) ESM
HF/DF
Max Range: 926 km
3RM-20 - (AN/SPS-63) Radar
Radar, Surface Search, Short-Range
Max Range: 74.1 km
WM.25 - (Low-Level AD, Missile FCS) Radar
Radar Illuminator, Long-Range
Max Range: 118.5 km
FL 1800SII [ESM] - (1997) ESM
ELINT
Max Range: 926 km
FL 1800SII [ECM] - (1997) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
TRS-3D/32 - (Naval TRM-S 3D) Radar
Radar, Air & Surface Search, 3D Medium-Range
Max Range: 185.2 km
WBA - (Gun FC) Infrared
Infrared, Weapon Director & Target Tracking and Identification Camera
Max Range: 185.2 km
STIR 180 [Radar] - (Sea Sparrow) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 59.3 km
STIR 180 [IR Camera] - (Sea Sparrow) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 185.2 km
STIR 180 [TV Camera] - (Sea Sparrow) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 185.2 km
Weapons:
76mm/62 Compact HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
RIM-7M Sea Sparrow - (1985) Guided Weapon
Air Max: 25.9 km. Surface Max: 25.9 km.
27mm MLG-27 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 2.8 km. Land Max: 2.8 km.
MU-90 Impact - (2003, Ex-Murene, Ex-A.290) Torpedo
Subsurface Max: 7.4 km.
RGM-84D Harpoon IC - (1986) Guided Weapon
Surface Max: 138.9 km.
Bullfighter Chaff/Flare Seduction - Decoy (Expendable)
Surface Max: 1.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
RIM-116B RAM Blk I - (2001) Guided Weapon
Air Max: 11.1 km.
