General data:
Type: FFG - Guided Missile Frigate Max Speed: 25 kt
Crew: 120 Length: 96.6 m
Beam: 11.2 m Draft: 4.5 m
Displacement Full: 1970 t Displacement: 1670 t
Operator: Navy Commissioned: 1997
Propulsion: 2x Babcock & Wilcox Boilers, 2x Laval-Ljungstrom PN 20 Geared Steam Turbines Decommissioned: 2007
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
9LV200 Mk2 [Radar] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Radar
Radar, FCR, Weapon Director
Max Range: 14.8 km
9LV200 Mk2 [TV Camera] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Visual
Visual, Weapon Director TV Camera
Max Range: 148.2 km
9LV200 Mk2 [IR] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Infrared
Infrared, Weapon Director Camera
Max Range: 148.2 km
9LV200 Mk2 [Laser Rangefinder] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
TSM 2633 Spherion B - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 14.8 km
AWS.9(2.5D) - (1997, Type 996, Target Indication) Radar
Radar, Target Indicator, 2D Surface-to-Air
Max Range: 203.7 km
AR-700A(V)1 - (ASP-2000, Assoc w APECS II) ESM
ELINT
Max Range: 926 km
TSM 2633 Spherion A - (ASP-2000, Assoc w APECS II) VDS, Active/Passive Sonar
VDS, Active/Passive Variable Depth Sonar
Max Range: 29.6 km
Mk95 [EO] - (Mk6 Mod 0, Mk91 FCS) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 148.2 km
Mk95 [Radar] - (MFCR, Mk91 FCS) Radar
Radar Illuminator, Medium-Range
Max Range: 118.5 km
Decca 1226 - (MFCR, Mk91 FCS) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Weapons:
Terne III ASW Rocket Salvo [6 rnds] - Rocket
Subsurface Max: 4.6 km.
20mm/80 Rhinemetall Mk20 Rh202 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
76mm/50 Twin Frag Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
76mm/50 Twin HE Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
40mm/70 Single Bofors Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
RIM-7M Sea Sparrow - (1985) Guided Weapon
Air Max: 25.9 km. Surface Max: 25.9 km.
Mk216 Sea Gnat Chaff [Distraction] - (1988) Decoy (Expendable)
Surface Max: 1.9 km.
Mk214 Sea Gnat Chaff [Seduction] - (1987) Decoy (Expendable)
Surface Max: 1.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Stingray Mod 0 - (1986) Torpedo
Subsurface Max: 7.4 km.
