General data:
Type: LPH - Amphibious Assault Helicopter Carrier Max Speed: 23 kt
Crew: 667 Length: 184.0 m
Beam: 31.7 m Draft: 7.9 m
Displacement Full: 18474 t Displacement: 17000 t
Operator: Navy Commissioned: 1986
Propulsion: 1x Boiler, 2x Steam Turbines
Sensors / EW:
Mk51 [Mk115 MFCS] - Radar
Radar Illuminator, Medium-Range
Max Range: 37 km
AN/SLQ-32(V)3 [ECM] - (Group, 1983) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
AN/SLQ-32(V)3 [ESM] - (Group, 1983) ESM
ELINT
Max Range: 926 km
AN/SPS-65(V)1 - (BPDMS, MPDR-45, AN/SPS-58) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 64.8 km
AN/SPS-67(V)1 - (1982) Radar
Radar, Surface Search & Navigation
Max Range: 64.8 km
AN/SPS-40 - (1963) Radar
Radar, Air Search, 2D Long-Range
Max Range: 407.4 km
AN/SPS-64(V)9 [RM 1220 6X] - (20kW, USN, 1x antenna) Radar
Radar, Surface Search & Navigation
Max Range: 37 km
Weapons:
RIM-7E Sea Sparrow - (1967, Mk25) Guided Weapon
Air Max: 11.1 km. Surface Max: 11.1 km.
20mm/85 Mk15 Phalanx Blk 0 Burst [200 rnds] - Gun
Air Max: 1.5 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk182 SRBOC Chaff [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
