General data:
Type: FFG - Guided Missile Frigate Max Speed: 25 kt
Crew: 120 Length: 96.6 m
Beam: 11.2 m Draft: 4.5 m
Displacement Full: 1970 t Displacement: 1670 t
Operator: Navy Commissioned: 1976
Propulsion: 2x Babcock & Wilcox Boilers, 2x Laval-Ljungstrom PN 20 Geared Steam Turbines
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
NO/SR-1A - (Norway, Missile boats) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
M.22 - (Gun, WM.20-Series) Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 59.3 km
AN/SQS-36 - (Gun, WM.20-Series) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 11.1 km
MPDR-45/1 - (Gun, WM.20-Series) Radar
Radar, Air & Surface Search, 2D Medium-Range
Max Range: 231.5 km
TVT-300 [Camera] - (Group, 9LV100, MSI-80S FC) Visual
Visual, Weapon Director TV Camera
Max Range: 148.2 km
TVT-300 [Laser Rangefinder] - (Group, 9LV100, MSI-80S FC) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
Mk95 [EO] - (Mk6 Mod 0, Mk91 FCS) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 148.2 km
Mk95 [Radar] - (MFCR, Mk91 FCS) Radar
Radar Illuminator, Medium-Range
Max Range: 118.5 km
Decca 1226 - (MFCR, Mk91 FCS) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
SQA-16 Terne Attack Sonar - (Norway) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mortar Fire Control
Max Range: 2.8 km
Weapons:
Terne III ASW Rocket Salvo [6 rnds] - Rocket
Subsurface Max: 4.6 km.
20mm/80 Rhinemetall Mk20 Rh202 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
76mm/50 Twin Frag Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
76mm/50 Twin HE Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
RB 12 Penguin Mk1 - (1972) Guided Weapon
Surface Max: 27.8 km.
RIM-7H Sea Sparrow - (1976, Mk29) Guided Weapon
Air Max: 14.8 km. Surface Max: 14.8 km.
Mk46 LWT Mod 2 - (1972) Torpedo
Subsurface Max: 5.6 km.
