General data:
Type: FFL - Corvette Max Speed: 32 kt
Crew: 43 Length: 57.0 m
Beam: 8.0 m Draft: 2.0 m
Displacement Full: 425 t Displacement: 380 t
Operator: Navy Commissioned: 2000
Propulsion: 3x MTU 16V 396 TB94 Diesels
Sensors / EW:
Pilot Mk.2 - (LPI) Radar
Radar, Surface Search & Navigation
Max Range: 88.9 km
Sceptre Lens - (Manta) ESM
ELINT
Max Range: 926 km
TSM 2643 Salmon - (Manta) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 7.4 km
SA 950 - (Elma attack sonar) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mine Hunting & ASW Mortar Fire Control [Detection & Classification]
Max Range: 1.1 km
PS-76 & PS 722 [Sea Giraffe 150 HC & ArtE 722E Surveillance] - (1990, CA/SPS-505) Radar
Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface
Max Range: 100 km
CEROS 200 Tracker [9LV Mk3 Basic] - (Group, PE 723 Radar, 9GR400) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 46.3 km
EOS 500 [CCD] - (Group, PE 723 Radar, 9GR400) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, PE 723 Radar, 9GR400) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, PE 723 Radar, 9GR400) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
Weapons:
Philax Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
Philax Flare - Decoy (Expendable)
Surface Max: 1.9 km.
RB 15M Mk2 - (1997) Guided Weapon
Surface Max: 148.2 km.
57mm/70 Bofors Mk2 GP Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 9.3 km. Land Max: 9.3 km.
40mm/70 Single Bofors Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
Tp 432 - (1990, Air & Ship, Light) Torpedo
Subsurface Max: 7.4 km.
Elma ASW-601 ASW Mortar Salvo [M90 Hard Kill DC, 9 rnds] - (1997) Depth Charge
Subsurface Max: 0.6 km.
