General data:
Type: CVA - Attack Carrier Max Speed: 32 kt
Crew: 5380 Length: 326.0 m
Beam: 39.5 m Draft: 10.9 m
Displacement Full: 81780 t Displacement: 60935 t
Operator: Navy Commissioned: 1985
Propulsion: 8x Boilers, 4x Steam Turbines Decommissioned: 1987
Sensors / EW:
AN/WLR-11 - (RWR for AN/WLR-1G, Improved AN/WLR-3 & AN/ALR-52) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/WLR-1G - (RWR for AN/WLR-1G, Improved AN/WLR-3 & AN/ALR-52) ESM
ELINT
Max Range: 926 km
AN/SPS-48C - (1978) Radar
Radar, Air Search, 3D Long-Range
Max Range: 407.4 km
Furuno - (Generic) Radar
Radar, Surface Search & Navigation
Max Range: 37 km
AN/SPS-10B - (Generic) Radar
Radar, Surface Search & Navigation
Max Range: 74.1 km
AN/SPS-49(V)1 - (1975) Radar
Radar, Air Search, 2D Long-Range
Max Range: 463 km
AN/SPN-43A - (1976) Radar
Radar, Shipboard Air Traffic Control (SATC)
Max Range: 129.6 km
Mk95 [EO] - (Mk6 Mod 0, Mk91 FCS) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 148.2 km
Mk95 [Radar] - (MFCR, Mk91 FCS) Radar
Radar Illuminator, Medium-Range
Max Range: 118.5 km
AN/SLQ-17 [ECM] - (Group, SLQ-29) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
AN/SLQ-17 [ESM] - (Group, SLQ-29) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons:
RIM-7M Sea Sparrow - (1985) Guided Weapon
Air Max: 25.9 km. Surface Max: 25.9 km.
20mm/85 Mk15 Phalanx Blk 0 Burst [200 rnds] - Gun
Air Max: 1.5 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk182 SRBOC Chaff [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
7.62mm MG Burst [20 rnds] - (Ship & Facility) Gun
Surface Max: 0.4 km. Land Max: 0.4 km.
