General data:
Type: FFG - Guided Missile Frigate Max Speed: 28 kt
Crew: 180 Length: 113.4 m
Beam: 12.5 m Draft: 5.8 m
Displacement Full: 2940 t Displacement: 2305 t
Operator: Navy Commissioned: 2012
Propulsion: 2x Babcock & Wilcox Boilers, 2x Werkspoor-English Electric Double-Reduction Geared Steam Turbines
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
PDE-700 [EDO 700, AN/SQS-35 Derivative] - (AK 1200) VDS, Active Only Sonar
VDS, Active-Only Variable Depth Sonar
Max Range: 11.1 km
PHS-32 - (AK 1200) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 7.4 km
M.45 - (GFCS, M40) Radar
Radar, FCR, Weapon Director
Max Range: 29.6 km
DA.05 [RAWS-3] - (GFCS, M40) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 237.1 km
LW.03 [SGR.114] - (GFCS, M40) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 185.2 km
Decca 1229 - (BPS-02) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Newton Beta [ELT 318/521, ECM] - (BPS-02) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
LIOD Mk.2 [IR] - (Group) Infrared
Infrared, Weapon Director Camera
Max Range: 148.2 km
LIOD Mk.2 [Laser Rangefinder] - (Group) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 0 km
LIOD Mk.2 [Optronic] - (Group) Visual
Visual, Weapon Director TV Camera
Max Range: 148.2 km
Newton Beta [ELT 211, ESM] - (Group) ESM
ELINT
Max Range: 926 km
Weapons:
Corvus Chaff [Seduction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Corvus Chaff [Distraction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
76mm/62 Compact HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
C-802 - (1995, Iranian Noor 2, Not adopted by China) Guided Weapon
Surface Max: 129.6 km.
Mk46 LWT Mod 2 - (1972) Torpedo
Subsurface Max: 5.6 km.
