General data:
Type: ML - Minelayer Max Speed: 20 kt
Crew: 85 Length: 105.7 m
Beam: 15.2 m Draft: 4.7 m
Displacement Full: 0 t Displacement: 3800 t
Operator: Navy Commissioned: 1982
Propulsion: 4x Nohab-Polar F212-D825 Diesels Decommissioned: 2001
Sensors / EW:
PN-619 [Scanter] - (Scanter 009?) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
PS-751 & PS 726 [Sea Giraffe 50 HC & ArtE 726E Surveillance] - (1984) Radar
Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface
Max Range: 55.6 km
9LV200 Mk2 [Radar] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Radar
Radar, FCR, Weapon Director
Max Range: 14.8 km
9LV200 Mk2 [TV Camera] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Visual
Visual, Weapon Director TV Camera
Max Range: 148.2 km
9LV200 Mk2 [IR] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Infrared
Infrared, Weapon Director Camera
Max Range: 148.2 km
9LV200 Mk2 [Laser Rangefinder] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
SQ-3D/SF - (Norway) Hull Sonar, Active-Only
Hull Sonar, Active-Only Search
Max Range: 2.8 km
PQ-868 [AR-700 Phoenix I] - (1984, ASP-32, Assoc w PQ 844) ESM
ELINT
Max Range: 926 km
Weapons:
57mm/70 Bofors Mk1 HCER Burst [4 rnds] - Gun
Surface Max: 8.3 km. Land Max: 8.3 km.
57mm/70 Bofors Mk1 HE Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 8.3 km. Land Max: 8.3 km.
40mm/70 m/48 Single Bofors Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
7.62mm MG Burst [20 rnds] - (Ship & Facility) Gun
Surface Max: 0.4 km. Land Max: 0.4 km.
Philax Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
