General data:
Type: FFL - Corvette Max Speed: 35 kt
Crew: 49 Length: 63.0 m
Beam: 9.3 m Draft: 2.6 m
Displacement Full: 600 t Displacement: 550 t
Operator: Navy Commissioned: 1997
Propulsion: 4x MTU 20V 538 TB93 Diesels
Sensors / EW:
ZW.06 - (1972, PIN 515) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Type 1007 - (1988, KH 1007) Radar
Radar, Surface Search & Navigation
Max Range: 177.8 km
Sea Giraffe 150 HC - (1990, CA/SPS-505, PS 76) Radar
Radar, Target Indicator, 3D Surface-to-Air
Max Range: 100 km
TSM 2640 Salmon - (1990, CA/SPS-505, PS 76) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 7.4 km
EL/M-2221-GM STGR - (Barak FCR) Radar
Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface
Max Range: 111.1 km
RAN-1010 MBAT [SEWS] - (Rafael, RAN-1101, 1110 or Shark system) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
MSIS [IR] - (Group, 1991) Infrared
Infrared, Weapon Director Camera
Max Range: 37 km
MSIS [EO] - (Group, 1991) Visual
Visual, Weapon Director TV Camera
Max Range: 37 km
MSIS [Laser Rangefinder] - (Group, 1991) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 0 km
NS-9003A - (3rd Gen, Assoc w RAN-1010) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
Weapons:
76mm/62 Super Rapido HE Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
Plessey Shield Flare - Decoy (Expendable)
Surface Max: 1.9 km.
Plessey Shield Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
A.244S - (1986, NST58) Torpedo
Subsurface Max: 5.6 km.
RGM-84D Harpoon IC - (1986) Guided Weapon
Surface Max: 138.9 km.
Barak I - (1997) Guided Weapon
Air Max: 11.1 km.
