General data:
Type: FFL - Corvette Max Speed: 23 kt
Crew: 90 Length: 80.5 m
Beam: 10.3 m Draft: 3.0 m
Displacement Full: 1250 t Displacement: 1100 t
Operator: Navy Commissioned: 1973
Propulsion: 2x SEMT-Pielstick 12 PC2 V400 Diesels
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
ARBR 16 [DR 2000S] - (AK 1200) ESM
ELINT
Max Range: 926 km
DRBV 51A Triton [TRS 3035] - (Exocet FC + Low Level Air Search) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 101.9 km
DUBA 25A Tarpon [TSM 2400] - (375mm Borfors ASW Mortar FC) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Mortar Fire Control
Max Range: 2.8 km
Panda [Optical] - (Group) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
DRBC 32 - (GFCR) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
Decca 1226 - (GFCR) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Weapons:
Bofors 375mm ASW Rocket Salvo [6 rnds] - Rocket
Subsurface Max: 3.7 km.
L5 Mod 4 - (Surface, ASW) Torpedo
Subsurface Max: 7.4 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
100mm/55 Model 1968 PFHE - Gun
Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km.
100mm/55 Model 1968 HE - Gun
Surface Max: 13 km. Land Max: 13 km.
