General data:
Type: FF - Frigate Max Speed: 28 kt
Crew: 250 Length: 109.7 m
Beam: 12.5 m Draft: 4.2 m
Displacement Full: 2960 t Displacement: 2500 t
Operator: Navy Commissioned: 1990
Propulsion: 2x Babcock & Wilcox Boilers, 2x Steam Turbines Decommissioned: 2006
Sensors / EW:
CA/SQS-505(V)2 [SQA-502 Hoist] - VDS, Active/Passive Sonar
VDS, Active/Passive Variable Depth Sonar
Max Range: 29.6 km
M.45 - (GFCS, M40) Radar
Radar, FCR, Weapon Director
Max Range: 29.6 km
ZW.06 - (1972, PIN 515) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
CA/SQS-505(V)1 - (Limbo Director) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Mortar Fire Control
Max Range: 29.6 km
INS-3 - (SLQ-747, Ajanta) ESM
ELINT
Max Range: 926 km
TQN-2 - (INS-3 Jammer/SLQ-747) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
LW.04 - (INS-3 Jammer/SLQ-747) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 222.2 km
LW.05 - (INS-3 Jammer/SLQ-747) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 259.3 km
Type 162M Cockshafer - (INS-3 Jammer/SLQ-747) Hull Sonar, Active-Only
Hull Sonar, Active-Only Bottom Profiler
Max Range: 1.3 km
Weapons:
Corvus Chaff [Seduction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Corvus Chaff [Distraction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Mk10 Limbo ASW Mortar Salvo [3 rnds] - Rocket
Subsurface Max: 0.9 km.
AK-230 30mm/65 Twin Burst [50 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
20mm/70 Oerlikon Mk7 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
A.244S - (1986, NST58) Torpedo
Subsurface Max: 5.6 km.
G738 [Type 182] Towed Torpedo Decoy - Decoy (Towed)
Surface Max: 1.9 km.
114mm/45 Mk6 Twin HE Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 18.5 km. Land Max: 18.5 km.
