General data:
Type: FFG - Guided Missile Frigate Max Speed: 30 kt
Crew: 140 Length: 114.0 m
Beam: 14.0 m Draft: 3.51 m
Displacement Full: 2900 t Displacement: 2300 t
Operator: Navy Commissioned: 2013
Propulsion: 1x Rolls-Royce MT30 Gas Turbine
Sensors / EW:
SMART-S Mk2 - Radar
Radar, Air & Surface Search, 3D Medium-Range
Max Range: 250 km
K/SLQ-200(V)K Sonata [ECM] - (Argo Phoenix mod, AR-700A) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
K/SLQ-200(V)K Sonata [ESM] - (Argo Phoenix mod, AR-700A) ESM
ELINT
Max Range: 926 km
DSQS-23B [CSU 90] - (Argo Phoenix mod, AR-700A) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 44.4 km
VAMPIR-MB [CCD] - (Group, 1996, Detector) Visual
LLTV, Target Search, Slaved Tracking and Identification
Max Range: 148.2 km
VAMPIR-MB [IR] - (Group, 1996, Detector) Infrared
Infrared, Target Search, Slaved Tracking and Identification Camera
Max Range: 148.2 km
VAMPIR-MB [Laser Rangefinder] - (Group, 1996, Detector) Laser Rangefinder
Laser Rangefinder
Max Range: 0 km
K/SPS-95K - (1998, Korea, GPS-98K) Radar
Radar, Surface Search & Navigation
Max Range: 200 km
Generic Acoustic Intercept - (1998, Korea, GPS-98K) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept
Max Range: 66.7 km
EOS 500 [CCD] - (Group, 9GR400, Stealth Gunhouse) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, 9GR400, Stealth Gunhouse) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, 9GR400, Stealth Gunhouse) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
CEROS 200 Tracker [9LV Mk3E CETRIS] - (Group, 9GR400, Stealth Gunhouse) Radar
Radar, FCR, Weapon Director
Max Range: 46.3 km
Weapons:
DAGAIE Mk2 LIR Flare - Decoy (Expendable)
Surface Max: 1.9 km.
DAGAIE Mk2 LEM Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
K-745 Blue Shark [Chung Sang Eo] - (South Korea, 2008, ASW, Chung Sang Eo) Torpedo
Subsurface Max: 5.6 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
127mm/62 HE-CVT [HiFrag] - Gun
Air Max: 2.8 km. Surface Max: 22.2 km. Land Max: 24.1 km.
127mm/62 HE-PD [HiCap] - Gun
Air Max: 2.8 km. Surface Max: 22.2 km. Land Max: 24.1 km.
127mm/62 WP - Gun
Surface Max: 22.2 km. Land Max: 24.1 km.
RIM-116A RAM Blk 0 - (1993) Guided Weapon
Air Max: 11.1 km.
20mm/100 Mk15 Phalanx Blk 1B Burst [300 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km.
7.62mm MG Burst [20 rnds] - (Ship & Facility) Gun
Surface Max: 0.4 km. Land Max: 0.4 km.
SSM-700K Hae Sung I - (2007, South Korea) Guided Weapon
Surface Max: 148.2 km.
K/SLQ-261 Torpedo Decoy - (Acoustic Countermeasure) Decoy (Expendable)
Surface Max: 1.9 km.
