General data:
Type: CV - Aircraft Carrier Max Speed: 26 kt
Crew: 763 Length: 195.1 m
Beam: 24.4 m Draft: 6.7 m
Displacement Full: 17188 t Displacement: 15912 t
Operator: Navy Commissioned: 1991
Propulsion: 2x General Electric LM-2500 Gas Turbines
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
RAN-12L/X - (SPQ-712, Meroka Search Radar) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 46.3 km
RAN-11L/X - (SPQ-712, Meroka Search Radar) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 46.3 km
AN/SPS-55 - (SPQ-712, Meroka Search Radar) Radar
Radar, Surface Search & Navigation
Max Range: 64.8 km
AN/SPS-52D - (SPQ-712, Meroka Search Radar) Radar
Radar, Air Search, 3D Long-Range
Max Range: 453.7 km
EN/SLQ-610 Nettunel Mk3200 [ELT 318/521, ECM] - (Spain Canopus) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
EN/SLQ-610 Nettunel Mk3200 [ELT 211, ESM] - (Spain, Deneb) ESM
ELINT
Max Range: 926 km
Radamec 2100 RNEOSS - (Spain, Deneb) Visual
Visual, Weapon Director & Target Search, Tracking and Identification TV Camera
Max Range: 55.6 km
AN/SPN-35A - (Spain, Deneb) Radar
Radar, Air Traffic Control (ATC)
Max Range: 74.1 km
Weapons:
20mm/120 Meroka Mod 2 Burst [144 rnds] - (1986) Gun
Air Max: 1.5 km.
Mk214 Sea Gnat Chaff [Seduction] - (1987) Decoy (Expendable)
Surface Max: 1.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
