General data:
Type: FFL - Corvette Max Speed: 28 kt
Crew: 124 Length: 97.3 m
Beam: 11.3 m Draft: 3.5 m
Displacement Full: 1900 t Displacement: 1690 t
Operator: Navy Commissioned: 1984
Propulsion: 4x MTU 20V 1163 TB92 Diesels
Sensors / EW:
DSQS-21C [CSU 83] - (FFL, Assoc w ASO 84) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 29.6 km
Rapids [Improved Sphinx] - (FFL, Assoc w ASO 84) ESM
ELINT
Max Range: 926 km
WM.22 - (Gun FCS, Larger Ships) Radar
Radar, FCR, Weapon Director
Max Range: 59.3 km
DA.08/1 - (Single Beam, PFN 513, AN/SPQ-50) Radar
Radar, Air & Surface Search, 2D Medium-Range
Max Range: 185.2 km
RAMSES [RWR] - (Scimitar) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
RAMSES [ECM] - (Scimitar) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Telegon [Generic] - (For ships with unspecified Telegon gear) ESM
HF/DF
Max Range: 926 km
LIOD Mk.1 [Optronic] - (Group) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
LIOD Mk.1 [IR] - (Group) Infrared
Infrared, Weapon Director Camera
Max Range: 74.1 km
LIOD Mk.1 [Laser Rangefinder] - (Group) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 0 km
Decca 1226 - (Group) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
ASO 84-5 [CSU 83] - (Assoc w DSQS-21C) VDS, Active/Passive Sonar
VDS, Active/Passive Variable Depth Sonar
Max Range: 29.6 km
Weapons:
Bofors 375mm ASW Rocket Salvo [2 rnds] - Rocket
Subsurface Max: 3.7 km.
57mm/70 Bofors Mk1 HCER Burst [4 rnds] - Gun
Surface Max: 8.3 km. Land Max: 8.3 km.
57mm/70 Bofors Mk1 HE Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 8.3 km. Land Max: 8.3 km.
DAGAIE Mk2 LIR Flare - Decoy (Expendable)
Surface Max: 1.9 km.
DAGAIE Mk2 LEM Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
100mm/55 Model 1968 PFHE - Gun
Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km.
100mm/55 Model 1968 HE - Gun
Surface Max: 13 km. Land Max: 13 km.
MM.38 Exocet Blk I - (1976) Guided Weapon
Surface Max: 42.6 km.
30mm/75 Twin Oerlikon APDS Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km.
30mm/75 Twin Oerlikon HE Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km.
