General data:
Type: CV - Aircraft Carrier Max Speed: 24 kt
Crew: 1015 Length: 211.3 m
Beam: 24.4 m Draft: 7.2 m
Displacement Full: 19890 t Displacement: 17500 t
Operator: Navy Commissioned: 1985
Propulsion: 4x Admiralty Boilers, 4x Parsons Steam Steam Turbines Decommissioned: 1987
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
MM/SPN-720 PAR - (Landing radar) Radar
Radar, Air Traffic Control (ATC)
Max Range: 46.3 km
DA.08/1 - (Single Beam, PFN 513, AN/SPQ-50) Radar
Radar, Air & Surface Search, 2D Medium-Range
Max Range: 185.2 km
LW.02 - (Single Beam, PFN 513, AN/SPQ-50) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 185.2 km
LW.08 - (RAWL-2, LAR-2, Type 1022, SPQ-502) Radar
Radar, Air Search, 2D Long-Range
Max Range: 333.4 km
ZW.01 [SGR.103] - (RAWL-2, LAR-2, Type 1022, SPQ-502) Radar
Radar, Air & Surface Search, 3D Short-Range
Max Range: 74.1 km
Decca - (Generic) Radar
Radar, Surface Search & Navigation
Max Range: 37 km
PAE-1 - (Assoc w CWE-10N) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mortar Fire Control
Max Range: 5.6 km
Weapons:
40mm/70 Single Bofors Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
