General data:
Type: DDG - Guided Missile Destroyer Max Speed: 29 kt
Crew: 280 Length: 155.0 m
Beam: 17.0 m Draft: 6.0 m
Displacement Full: 7100 t Displacement: 6000 t
Operator: Navy Commissioned: 2006
Propulsion: 2x Diesels, 2x Gas Turbines, CODOG
Sensors / EW:
China Type 347 - (GFCR, 100mm, EFR-1, Rice Lamp) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
China Type 381 Rice Screen - (Rice Field, Sea Eagle, God Eye) Radar
Radar, Air & Surface Search, 3D Long-Range
Max Range: 398.2 km
Tombstone [30N6-1] - (30N6E1, Naval) Radar
Radar, FCR, Surface-to-Air, Medium-Range
Max Range: 166.7 km
China BM/HZ 8610 [DR 4000] - (30N6E1, Naval) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
China Type 360 - (Sea Tiger, SR-60, S-3, Seagull-S) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 166.7 km
China SJD-9 [DUBV 23] - (Luda III, Luhu) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 14.8 km
China Type 362 - (ESR-1, SR-47A) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 74.1 km
Weapons:
SA-N-20b Gargoyle [48N6M] - (S-300FM) Guided Weapon
Air Max: 203.7 km. Surface Max: 46.3 km.
100mm/55 H/PJ-87 HECVT - Gun
Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km.
100mm/55 H/PJ-87 HE - Gun
Surface Max: 13 km. Land Max: 13 km.
30mm China H/PJ-12 [Type 730, 240 rnds] - (China, Goalkeeper Copy) Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
Yu-7 - (China, 1998?) Torpedo
Subsurface Max: 3.7 km.
Generic Flare Rocket [Single Spectral] - (Ship-only) Decoy (Expendable)
Surface Max: 1.9 km.
Generic Chaff Rocket - (Ship-only) Decoy (Expendable)
Surface Max: 1.9 km.
YJ-83 [C-802A, CSS-N-8 Saccade] - (1999) Guided Weapon
Surface Max: 185.2 km.
