General data:
Type: CV - Aircraft Carrier Max Speed: 28 kt
Crew: 2100 Length: 224.6 m
Beam: 39.6 m Draft: 8.7 m
Displacement Full: 28700 t Displacement: 22000 t
Operator: Navy Commissioned: 2009
Propulsion: 4x Admiralty Boilers, 2x Steam Turbines Decommissioned: 2016
Sensors / EW:
DA.05 [RAWS-3] - Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 237.1 km
Type 184M - (Solid State) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 5.6 km
Decca 1006 - (Solid State) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Type 965M Single Bedstead [MTI Mod] - (Type 966M, Post-Falklands MTI Mod) Radar
Radar, Air Search, 2D Long-Range
Max Range: 370.4 km
EL/M-2221-GM STGR - (Barak FCR) Radar
Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface
Max Range: 111.1 km
RAN-1010 MBAT [SEWS] - (Rafael, RAN-1101, 1110 or Shark system) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
C-Pearl - (Rafael, RAN-1101, 1110 or Shark system) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
Weapons:
Corvus Chaff [Seduction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Corvus Chaff [Distraction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
AK-230 30mm/65 Twin Burst [50 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
40mm/60 Mk3 Single Bofors Burst [2 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
Barak I - (1997) Guided Weapon
Air Max: 11.1 km.
