General data:
Type: FFG - Guided Missile Frigate Max Speed: 30 kt
Crew: 165 Length: 134.0 m
Beam: 16.0 m Draft: 3.5 m
Displacement Full: 4300 t Displacement: 3400 t
Operator: Navy Commissioned: 2005
Propulsion: 4x M.A.N. 16PA6V 280 STC Diesels, CODAD
Sensors / EW:
Crotale TV Tracker - (Group, Crotale FCR, Castor IIJ?) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 74.1 km
China Type 345 [Radar] - (Crotale) Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 29.6 km
Piranha [IR] - (Castor IIJ) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 148.2 km
Bull Nose [MG-332 Titan-2] - (Castor IIJ) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 5.6 km
Decca 1290 Master - (Castor IIJ) Radar
Radar, Surface Search & Navigation
Max Range: 37 km
China Type 363 - (MR-36) Radar
Radar, Target Indicator, 2D Surface-to-Air
Max Range: 129.6 km
China Type 364 - (SR-64, Seagull-C) Radar
Radar, Target Indicator, 2D Surface-to-Air
Max Range: 129.6 km
China Type 347G - (GFCR, 100mm, EFR-1, Rice Lamp) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
China Type 826 - (HZ100, Assoc w Type 984/985 Jammer) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Weapons:
China Type 87 ASW Rocket Salvo [6 rnds] - Rocket
Subsurface Max: 3.7 km.
AK-630M 30mm/65 Gatling Burst [400 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
YJ-83 [C-802A, CSS-N-8 Saccade] - (1999) Guided Weapon
Surface Max: 185.2 km.
100mm/55 H/PJ-87 HECVT - Gun
Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km.
100mm/55 H/PJ-87 HE - Gun
Surface Max: 13 km. Land Max: 13 km.
Yu-7 - (China, 1998?) Torpedo
Subsurface Max: 3.7 km.
HQ-7 Crotale [FM-80] Naval - (China, 1990, CSA-4) Guided Weapon
Air Max: 9.3 km. Surface Max: 9.3 km.
Generic Flare Rocket [Single Spectral] - (Ship-only) Decoy (Expendable)
Surface Max: 1.9 km.
Generic Chaff Rocket - (Ship-only) Decoy (Expendable)
Surface Max: 1.9 km.
