General data:
Type: FF - Frigate Max Speed: 25 kt
Crew: 197 Length: 102.7 m
Beam: 11.8 m Draft: 3.8 m
Displacement Full: 2250 t Displacement: 1760 t
Operator: Navy Commissioned: 1968
Propulsion: 4x SEMT-Pielstick 12 PC2.2 V400 Diesels
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
DUBA 3 - (305mm ASW Mortar FC) Hull Sonar, Active-Only
Hull Sonar, Active-Only Mortar Fire Control
Max Range: 1.9 km
AN/SQS-17 - (305mm ASW Mortar FC) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 11.1 km
DRBV 50 - (305mm ASW Mortar FC) Radar
Radar, Air & Surface Search, 2D Short-Range
Max Range: 46.3 km
DRBC 31D - (GFCR) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
DRBV 22A Jupiter - (GFCR) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 129.6 km
ARBR 10 - (GFCR) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Decca 1226 - (GFCR) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
DSBV 1 - (GFCR) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Torpedo Warning
Max Range: 27.8 km
Weapons:
L5 Mod 4 - (Surface, ASW) Torpedo
Subsurface Max: 7.4 km.
100mm/55 Model 1953 PFHE - Gun
Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km.
100mm/55 Model 1953 HE - Gun
Surface Max: 13 km. Land Max: 13 km.
40mm/70 Single Breda Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
305mm ASW Mortar Salvo [4 rnds] - Depth Charge
Subsurface Max: 0.6 km.
