General data:
Type: CV - Aircraft Carrier Max Speed: 30 kt
Crew: 825 Length: 180.2 m
Beam: 23.8 m Draft: 6.7 m
Displacement Full: 13850 t Displacement: 10100 t
Operator: Navy Commissioned: 2002
Propulsion: 4x General Electric-Fiat LM-2500 Gas Turbines, COGAG
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
MM/SPN-720 PAR - (Landing radar) Radar
Radar, Air Traffic Control (ATC)
Max Range: 46.3 km
DE 1160LF - (Landing radar) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 14.8 km
MM/SPS-774 [RAN-10S Pluto] - (NA-30B/E Search) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 166.7 km
MM/SPN-749 - (NA-30B/E Search) Radar
Radar, Surface Search & Navigation
Max Range: 74.1 km
MM/SPS-702 - (1986, SPQ-702?) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 74.1 km
MM/SPN-728(V)1 - (Navigation & Helicopter Control) Radar
Radar, Air & Surface Search, 3D Short-Range
Max Range: 74.1 km
MM/SPS-768 [RAN-3L] - (1976) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 277.8 km
AN/SPS-52C - (1976) Radar
Radar, Air Search, 3D Long-Range
Max Range: 453.7 km
MM/SPG-74 Dardo [Radar] - (RTN-20X, Gun) Radar
Radar, FCR, Weapon Director
Max Range: 13 km
MM/SPG-74 Dardo [TV Camera] - (Gun-Only) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
Galileo OG 30 [FLIR] - (Aspide-Only) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 185.2 km
MM/SPG-76 [Radar] - (RTN-30X, Aspide) Radar
Radar Illuminator, Medium-Range
Max Range: 46.3 km
MM/SLQ-732 Nettuno [ELT 211, ESM] - (Italy) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
MM/SLQ-732 Nettuno [ELT 318/521, ECM] - (Italy) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Weapons:
Aspide - (1980, SAM) Guided Weapon
Air Max: 18.5 km. Surface Max: 18.5 km.
40mm/70 Twin Breda Compact Burst [32 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
SCLAR Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
SCLAR Flare - Decoy (Expendable)
Surface Max: 1.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
A.244S - (1986, NST58) Torpedo
Subsurface Max: 5.6 km.
