General data:
Type: DDH - Helicopter Destroyer Max Speed: 27 kt
Crew: 292 Length: 128.8 m
Beam: 15.2 m Draft: 4.7 m
Displacement Full: 5100 t Displacement: 4450 t
Operator: Navy Commissioned: 1976
Propulsion: 2x General Motors Allison 570KF Gas Turbines, 2x Pratt & Whitney FT4-A2 Gas Turbines, COGOG
Sensors / EW:
CA/SQS-505(V)2 [SQA-502 Hoist] - VDS, Active/Passive Sonar
VDS, Active/Passive Variable Depth Sonar
Max Range: 29.6 km
MM/SPQ-2D - Radar
Radar, Air & Surface Search, 2D Short-Range
Max Range: 74.1 km
CA/SPS-501 [LW.03] - (1968) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 185.2 km
CA/SQS-505(V)1 - (Limbo Director) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Mortar Fire Control
Max Range: 29.6 km
WM.22 - (Missile FCS, Larger Ships) Radar
Radar Illuminator, Medium-Range
Max Range: 59.3 km
AN/ULQ-6C - (AN/SLQ-26) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
AN/WLR-1F - (AN/SLQ-26) ESM
ELINT
Max Range: 926 km
CA/SQS-501 [Type 162 Cockshafer] - (AN/SLQ-26) Hull Sonar, Active-Only
Hull Sonar, Active-Only Bottom Profiler
Max Range: 0.7 km
CA/UPD-501 ESM - (1952-1998) ESM
ELINT
Max Range: 926 km
CA/SRD-501 HF/DF [Telegon 4] - (1952-1998) ESM
HF/DF
Max Range: 55.6 km
Weapons:
Corvus Chaff [Seduction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Corvus Chaff [Distraction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
RIM-7H Sea Sparrow - (1976, Mk29) Guided Weapon
Air Max: 14.8 km. Surface Max: 14.8 km.
Mk10 Limbo ASW Mortar Salvo [3 rnds] - Rocket
Subsurface Max: 0.9 km.
127mm/54 OTO Melara Compact HECVT - Gun
Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km.
127mm/54 OTO Melara Compact HiCap - Gun
Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km.
Mk46 LWT Mod 1 - (1969, Major version) Torpedo
Subsurface Max: 5.6 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
