General data:
Type: FF - Frigate Max Speed: 31 kt
Crew: 175 Length: 117 m
Beam: 12.7 m Draft: 6.8 m
Displacement Full: 3250 t Displacement: 2750 t
Operator: Navy Commissioned: 2000
Propulsion: 2x Rolls-Royce Tyne Cruise Gas Turbines, 2x Rolls-Royce Olympus Boost Gas Turbines, COGOG Decommissioned: 2023
Sensors / EW:
China HQ-64 Illuminator - Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 29.6 km
DA.08/1 - (Single Beam, PFN 513, AN/SPQ-50) Radar
Radar, Air & Surface Search, 2D Medium-Range
Max Range: 185.2 km
Type 162M Cockshafer - (Single Beam, PFN 513, AN/SPQ-50) Hull Sonar, Active-Only
Hull Sonar, Active-Only Bottom Profiler
Max Range: 1.3 km
Type 1006(2) [KH 19/9A] - (Surface Ships) Radar
Radar, Surface Search & Navigation
Max Range: 118.5 km
Type 184M - (Solid State) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 5.6 km
ATAS(V)1 - (Solid State) TASS, Active Towed Array Sonar System
TASS, Active-Only Towed Array Sonar System
Max Range: 74.1 km
CEROS 200 Tracker [9LV Mk3 Basic] - (Group, PE 723 Radar, 9GR400) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 46.3 km
EOS 500 [CCD] - (Group, PE 723 Radar, 9GR400) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, PE 723 Radar, 9GR400) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, PE 723 Radar, 9GR400) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
Najir [Optical] - (Group, 1995, Remote-Controlled) Visual
Visual, Weapon Director TV Camera
Max Range: 148.2 km
Najir [IR] - (Group, 1995, Remote-Controlled) Infrared
Infrared, Weapon Director Camera
Max Range: 148.2 km
Najir [Laser Rangefinder] - (Group, 1995, Remote-Controlled) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
DR 3000S1X - (Group, 1995, Remote-Controlled) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
Weapons:
Corvus Chaff [Seduction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Corvus Chaff [Distraction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Type 182 Towed Torpedo Decoy - Decoy (Towed)
Surface Max: 1.9 km.
Tp 43X0 - (2000, Export) Torpedo
Subsurface Max: 7.4 km.
30mm/75 Single Oerlikon APDS Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km.
30mm/75 Single Oerlikon HE Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km.
114mm/55 Mk8 HE(MP) HE - Gun
Air Max: 2.8 km. Surface Max: 18.5 km. Land Max: 18.5 km.
HQ-64 [Aspide, LY-60N] - Guided Weapon
Air Max: 18.5 km. Surface Max: 18.5 km.
20mm GAM-BO1 Oerlikon Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
