General data:
Type: PF - Patrol Frigate Max Speed: 39 kt
Crew: 135 Length: 94.5 m
Beam: 11.1 m Draft: 3.3 m
Displacement Full: 1540 t Displacement: 1250 t
Operator: Navy Commissioned: 1998
Propulsion: 2x Paxman Ventura Diesels, 2x TM-3A Gas Turbines, CODOG
Sensors / EW:
China Type 352 Square Tie - (SSM, Rangout) Radar
Radar, FCR, Surface-to-Surface
Max Range: 74.1 km
FH-5 HF/DF - (UA-13) ESM
HF/DF
Max Range: 926 km
RDL-2 - (Assoc w RCM-2) ESM
ELINT
Max Range: 926 km
AWS.2 - (Assoc w RCM-2) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 111.1 km
RTN-10X (Orion 10X) - (1973, GFCR, Type 912) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
Decca 1226 - (1973, GFCR, Type 912) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Weapons:
Corvus Chaff [Seduction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
Corvus Chaff [Distraction] - (102mm) Decoy (Expendable)
Surface Max: 1.9 km.
35mm/90 Twin Frag Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km.
114mm/55 Mk8 HE(MP) HE - Gun
Air Max: 2.8 km. Surface Max: 18.5 km. Land Max: 18.5 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
C-802 - (1995, Iranian Noor 2, Not adopted by China) Guided Weapon
Surface Max: 129.6 km.
20mm GAM-BO1 Oerlikon Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
