General data:
Type: FFG - Guided Missile Frigate Max Speed: 26 kt
Crew: 200 Length: 103.2 m
Beam: 10.8 m Draft: 3.1 m
Displacement Full: 1661 t Displacement: 1425 t
Operator: Navy Commissioned: 1999
Propulsion: 2x 12PA68TC Diesels
Sensors / EW:
China Type 352 Square Tie - (SSM, Rangout) Radar
Radar, FCR, Surface-to-Surface
Max Range: 74.1 km
China Type 343 Sun Visor [Radar] - (Group, 100mm FCS) Radar
Radar, FCR, Weapon Director
Max Range: 27.8 km
China Type 343 Wasp Head [Visual Director] - (Group, 100mm FCS) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
China Type 354 Eye Shield - (2D, MX-902) Radar
Radar, Air & Surface Search, 3D Medium-Range
Max Range: 185.2 km
Decca 1290 Master - (2D, MX-902) Radar
Radar, Surface Search & Navigation
Max Range: 37 km
China SJD-5 [Tamir-11 Impr] - (Jianghu II, EH-5) Hull Sonar, Active-Only
Hull Sonar, Active-Only Search
Max Range: 7.4 km
China Type 756 Fin Curve Mod [Decca 1229 Copy] - (Jianghu II, EH-5) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
Triton IV - (Ship, Export AN/ALR-66B(V)3, Locator 2000) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
Triton IV MBAT - (Locator 2000 ECM element) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Weapons:
Depth Charge [Generic] - Depth Charge
Subsurface Max: 0.2 km.
China Type 81 ASW Rocket Salvo [5 rnds] - (RBU-1200) Rocket
Subsurface Max: 1.9 km.
57mm/70 Twin HE Burst [2 rnds] - Gun
Air Max: 2.2 km. Surface Max: 8.3 km. Land Max: 8.3 km.
37mm/63 Twin Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
HY-1J [CSS-N-2 Safflower, Ship] - (1979) Guided Weapon
Surface Max: 129.6 km.
