F 134 Laksamana Hang Nadim [Assad Class] - 1998, 4x, Orig. Intended for Iraq
| General data: | |
|---|---|
| Type: FFL - Corvette | Max Speed: 37 kt |
| Crew: 51 | Length: 62.3 m |
| Beam: 9.3 m | Draft: 2.8 m |
| Displacement Full: 700 t | Displacement: 620 t |
| Operator: Navy | Commissioned: 1998 |
| Propulsion: 4x MTU 20V 956 TB92 Diesels |
| Sensors / EW: |
|---|
| Type 1007 - (1988, KH 1007) Radar Radar, Surface Search & Navigation Max Range: 177.8 km |
| RAN-12L/X - (SPQ-712, Meroka Search Radar) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 46.3 km |
| RTN-10X (Orion 10X) - (1973, GFCR, Type 912) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| RTN-10X (Orion 10X) + RTN-12 Sirio CW - (1973, MFCS) Radar Radar Illuminator, Medium-Range Max Range: 37 km |
| DSQS-21C [CSU 83] - (FFL, Assoc w ASO 84) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 29.6 km |
| ASO 84-41 [CSU 83] - (Assoc w DSQS-21C) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 29.6 km |
| INS-3 - (SLQ-747, Ajanta) ESM ELINT Max Range: 926 km |
| TQN-2 - (INS-3 Jammer/SLQ-747) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| Weapons: |
|---|
| 76mm/62 Super Rapido HE Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 40mm/70 Twin Breda Compact Burst [32 rnds] -
Gun Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km. |
| Otomat Mk2 Mod I -
(1980) Guided Weapon Surface Max: 185.2 km. |
| A.244S -
(1986, NST58) Torpedo Subsurface Max: 5.6 km. |
| Aspide -
(1980, SAM) Guided Weapon Air Max: 18.5 km. Surface Max: 18.5 km. |
| SCLAR Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
| SCLAR Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
