General data:
Type: Wild Weasel Crew: 2
Min Speed: 350 kt Max Speed: 920 kt
Wingspan: 10.7 m Height: 6.0 m
Length: 19.6 m Max Payload: 6700 kg
Empty Weight: 12470 kg Max Weight: 23834 kg
Operator: Air Force Commissioned: 1975
Propulsion: 2x J75-P-19W Decommissioned: 1980
Sensors / EW:
AN/APR-37 - (J/APR-2) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/APS-107 STARM Target Acquisition - (J/APR-2) ESM
Emitter Locator (For ARM Missiles)
Max Range: 222.2 km
AN/ALQ-105 - (F-105G) ECM
DECM, Defensive ECM
Max Range: 0 km
AN/ALR-31 RHAWS - (F-105G) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
NASARR R-14A - (F-105) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 29.6 km
Weapons / Loadouts:
AGM-78D Standard [ARM] - (1975) Guided Weapon
Surface Max: 92.6 km. Land Max: 92.6 km.
450 USG Drop Tank - Drop Tank
AGM-45B Shrike [ARM] - (1975-1992) Guided Weapon
Surface Max: 46.3 km. Land Max: 46.3 km.
650 USG Drop Tank - Drop Tank
